Pilot Operated Proportional Directional Control Valve – Series D31FB OBE / D41FB OBE / D91FB OBE / D111FB OBE
Part #: D91FBE01HC4NF00
Technical Specifications
| Port Connection: | NG25 / CETOP 08 |
| Operation Type: | Pilot |
| Actuation Type: | Proportional solenoid |
| Function: | 3-way |
| Flow Rate: | 400 L/Min |
| Maximum Flow Rate: | N/A |
| Spool Position: | Operated in position a or b |
| Maximum Operating Pressure: | 350 bar |
| Pilot Inlet / Drain Locations: | Internal / internal |
| Seal Material: | NBR |
| Maximum Operating Temperature: | 60 °C |
| Signal Input: | 0 – ±10 V |
| Minimum Operating Temperature: | -20 °C |
| Flow Direction: | 0 – +10 V = P-B |
| For Fluid Type: | Hydraulic oil according to DIN 51524 … 535, Water glycol |
| Weight: | 21.1 kg |
| Product Series: | Proportional DC valve |
| Mounting Type: | Subplate mounting |
| Seal Material: | NBR |
| Body Material: | Cast iron |
| Valve Option: | Standard |
| Connection Type: | 6 + PE |
| Spool Code: | E01 |
Details
| Weight | 12 kg |
|---|---|
| Dimensions | 30 × 30 × 30 cm |
